Tiller / Disc Harrow

HTLS tiller series  - for working widths from 140cm to 200cm

Heavy duty Tiller cultivator for medium tractors with 35hp to 70hp for CAT I / CAT II 3-point hitch

Application :

The Twins Industry HTLS tiller is a professional tractor tiller for thorough tilling any kind of soil on medium and larger sized land. The working width of 140cm to 200cm and the adjustable working depth of up to 18cm makes the Victory HTLS tiller superior to standard tillers in this price segment.

In contrast to other tiller offered in the market, we use between 42 and 60 specially hardened blades made from alloy steel, each with a weight of 720gr.

Unlike other tiller using a chain or belt for transmission, the Victory HTLS tiller is using a heavy maintenance-free oil bath gear transmission, letting the laser balanced blade shaft run smoothly through even heavy and hard soil.

Technology :

Underneath the tiller´s massive up to 6mm strong steel housing sits the laser balanced shaft with flanges in 25cm distance, each equipped with 6 specially designed blades. The blades are made of hardened boron steel and can be individually exchanged or regrinded.

The reinforced free-wheel transmission lets the rotor shaft of the tiller turn, once the PTO is switched off, so that its movement will not be transferred to the tractor.  The PTO shaft supplied with the tiller has a friction clutch for a perfect protection. The lower hitch Cat I / II connectors of the tiller can be adjusted to perfectly position your HTLS tiller behind your tractor and according to its track width.

The height adjustable rear cover of the tiller is providing a smooth finish to the loosened soil and is also an important safety feature,

The completely assembled HTLS tiller is delivered in the massive Victory wooden crates. Just the 3-point hitch and the PTO shaft protector have to be assembled to the tiller, taking you less than 20min. We offer a multilingual user manual and assembly guide with photos to assist you.

side transmission with oil bath gear

.free-wheel transmission protects your tractor after PTO is switched off

.easy positioning of the tiller behind your tractor by our adjustable Cat I lower hitches (also works for Cat II)

.rear safety cover ; spring controlled

.front safety covers for HTLS tiller

.PTO shaft with friction clutch included in the shipment

.gear oil included in the shipment

.detailed multi-lingual user manual

.spare part service and detailed drawings available in our online shop

We from Twins Industry firmly believe that you will not find a better value for money heavy tiller in the market, please feel free to compare our product to the others in the market and we are sure you will agree.

ATTENTION

Partially assembled machines do not contain any fuel , oil or other fluids or grease needed for operation ! BEFORE USING THE MACHINE please carefully read the English user manual.
